CPU |
Centrality Atlas III 396MHz or Atlas Ⅳ 500MHz |
|
Memory |
Flash(ROM)--64MB or 128MB(Expenstional); RAM--64MB |
|
Display |
4.3' colour TFT Touch screen, 480*272 pixels |
|
GPS Receiver |
Sirf |
|
Operating System |
Microsoft Win CE Net 5.0 Core version |
|
Blue tooth (optional) |
Hands-free calling with most Blue tooth-enabled phones |
|
TMC (optional) |
Available; |
|
MP4 (optional) |
Video File Format: AVI; |
|
MP3 (optional) |
Audio File Format: Mp3 |
|
TXT (optional) |
Available |
|
Picture-Viewer (optional) |
Available |
|
Input Method |
Stylus pen, Software keyboard |
|
Expansion Slot |
SD Card, MMC Card; |
|
Speaker |
Build in 1.5W load speaker |
|
Headphone |
3.5mm Mini Jack; |
|
USB |
USB (Power supply for 3.5' device) |
|
Battery |
Rechargeable Li-ion Battery 2200mAh or 1500mAh |
|
Operating Temperature |
-10℃ to +60℃(Industrial Grade) |
|
Standard Accessories |
USB Cable, Car Charger, Car Mount, Suction Cap,Stylus pen, User manual, Gift Box |
|
Hot Start |
9sec(typ); |
|
Warm start |
38sec(typ); |
|
Cold Start |
43sec(typ) |
|
Satellite reacquisiton Time Accuracy |
100ms; |
|
Channel |
up to 16 |
|
Position Accuracy: |
up to 3m possible; |
|
Receiver |
L1(1575.42Mhz),C/A code(1.023Mhz) |
|
Protocol |
NMEA 0183 |
|
Maximum Altitude |
< 60.000 feet |
|
Maximum Velocity |
<700 knots; |
|
Max.update Rate |
1HZ ; |
|
RF Connector |
MCX to SMA |
|
Firmware upgrade |
Flash Eprom filed programming software available |
|
Time Mark |
Output 1 pulse/sec, aligned with GPS time ±0.1u sec |
|
Operating temperature |
-20℃ to +60℃; |
|
Storage temperature |
-65℃ to 150℃ |
